8 Inch Active Line Array System Line Array Speaker Box CE RoHS

Brand Name : CVR

Model Number : W-82C&W-15CP

Certification : CE.RoHS

Place of Origin : CHINA

MOQ : 2 Pieces

Price : Negoanited

Payment Terms : D/A, D/P, L/C, T/T, Western Union, MoneyGram

Supply Ability : 10000 Pieces Per Month

Delivery Time : 3-10 Days

Packaging Details : Carton Box Or Flightcase

Size : 8 Inch Neodymium Woofers

Color : Black

Type : active mini line array

Apply : indoor shows,church,small show,sound events

Outlooking : Textured Black Paint

Feature : Water-Proof and Durable

Contact Now

8 Inch Active Line Array System , Line Array Speaker Box CE RoHS

Specification:

W-82C is a line array system which is made of a 8＂woofer, a 1.75＂titanium compression driver and high performance low distortion compression driver with innovative horn design of wave phase philosophy. Wherever low frequency extension is required, a W-82C will integrate seamlessly with W-15C or W-15CP line array sub-bass system in a standard configuration. Each enclosure is equipped with rigging system, allowing flown array to be constructed rapidly and safely. W-82C is very versatile and scalable for a wide range of applications in touring performance, corporate and fixed installation fields.

W-15C/W-15CP is a dedicated high performance sub-bass system designed to augment the low frequency output of W-82C. W-15C/W-15CP is a sub-bass enclosure which must be flown with W-82C. So its physical dimensions are identical to the W-82C and it is equipped with the same proprietary rigging system. It features with a 15＂woofer with magnet structure and suspensions engineered for maximum linear excursion. The W-15CP with Bluetooth features a highly efficient power amp module and incorporated DSP.

Model	W-82C ＆ W-15C/W-15CP(Active)
Type	Line arry system
Type	line arry sub-bass system(W-15C/W-15CP)
Frequency Response	70Hz-20KHz±3dB
Frequency Response	40Hz-500Hz±3dB(W-15C/W-15CP)
Power handling	250W(RMS)500W(PEAK)
Power handling	500W(RMS)1000W(PEAK)(W-15C/W15CP)
Power amp	2X600W/4ohm + 1X900W/8ohm(W-15CP)
Amplifier type	Switching power amp, class D circuit
Other functions	Bluetooth,DSP (W-15CP)
Sensitivity	96dB(1W@1M)
Sensitivity	106dB(1W@1M)(W-15C/W15CP)
Max@S.P.L	116dB(PEAK/1M)
Max@S.P.L	130dB(1W@1M)(W-15C/W15CP)
LF section	1×8"(210mm)woofer 50mm(2in)coil
LF section	15"(380mm)woofer 100mm(4in)coil (W-15C/W-15CP)
HF section	1×1.75"compression driver with44mm titanium diaphragm
Nominal impedance	8 ohm(W-82C)& 8 ohn (W-15C/W-15CP)
Output section	2-channel
Dispersion pattern	110º H×9º V
Surface finish	Black paint
Array design	Arrays of less than 3×W-82C will provide poor dispersion control and are neither recommended nor supported
Speaker cables	1(+)1(-) Built in crossover
Rigging system	Please refer to the W-82C user's manual before any operation
Input connectors	2×NL4MP speakon
Recommend crossover	70Hz-20KHz
Recommend crossover	40Hz-100Hz(W-15C/W-15CP)
Dimensions	544×245×375mm(W×H×D)
Dimensions	515×450×611mm(W×H×D) (W-15C/W-15CP)
Package dimensions	615×315×445mm/0.09cbm
Package dimensions	585×520×680mm/0.22cbm (W-15C/W-15CP)
Enclosure	HLPE(W-82C)/Plywood(W-15C/W-15CP)
Net weight	12.5kg(W-82C)/34kg(W-15C)/40kg(W-15CP)
Gross weight	14.5kg(W-82C)/37kg(W-15C)/43kg(W-15CP)
